Pressure & frequency control
Include the target pressure, demand range, number of pumps and motor details. The proposed drive and pressure signal should be reviewed as part of the complete control arrangement.
Describe the pressure requirement
XY500 catalogue range
The catalogue shows more than one enclosure in the XY500 range. Specify the motor and control task first; the proposed version and its ratings follow in the quotation.
Series reference image. Confirm the appearance, dimensions and specification of the model quoted for your order.
Describe the required pressure switching behaviour and the existing installation. A pressure-control label does not by itself identify a variable-frequency drive.
Explore control panel referencesState the intended pressure-control objective, demand variation and feedback arrangement. The motor, drive and sensing input need to be reviewed together.
Download Excel formSeries reference / XY500
XY500 appears in the source catalogue as a variable-frequency control series. A specific model and its electrical ratings need to be identified before a product configuration can be quoted.
No model-level power or voltage selection is listed here. Request the technical sheet for the proposed version.
Target pressure, expected flow range and the way demand changes.
Number of pumps, model, motor type and any standby or alternation requirement.
Site voltage, phase and frequency; existing pressure sensor and controller input.
Drive alone or a control assembly, with the required sensing, documentation and accessories.
Tank filling
Bring together the pump duty and the tank-level control. Identify where the water comes from, how high it needs to rise and when the pump should stop.
Before the order
A model number is the starting point. The proposed configuration should be identifiable in the drawing, curve and electrical information you review.
Performance curve, dimensions and connection information for the proposed pump.
Electrical ratings, motor-drive match, wiring reference and the required control inputs.
A written list of the supplied pump, drive, installation components and documentation.
Your next step
For example: maintain pressure as outlets open and close. Add the known flow, pressure, motor and power supply details.
